Recessed directional spotlight, rotatable and tiltable
Recessed ring made of powder-coated sheet steel
Heat sink made of black anodized extruded aluminum
Housing made of die-cast aluminum with bayonet lock
Safety glass and reflector integrated into the bayonet ring
All visible parts powder-coated in RAL colors
Reflector made of aluminum, polished and anodized
Tool-free installation via spring mechanism
LED converter included
| Control | Luminous flux | Light color | Beam angle | Power consumption | Protection class |
|---|---|---|---|---|---|
| Dali | 4580 lm |
3000 K
|
21 °
|
41.5 W. | IP20 |
| Lifespan | L70B50 50,000 h @ 25 ° C |
| Ambient temperature | +5 ... + 35 ° C |
| Storage & transport temperature | -25 ... + 70 ° C |
| Weight | approx. 1.9 kg |
| Light output | 110 lm / W |
| Housing material | aluminum |
| Protection class | II |
| Protection class | IP20 |
| Color fidelity | SDCM 3 |
| Colour reproduction | >90 |
| Installation dimensions diameter [mm] | 190 |
| Installation dimensions height [mm] | 180 |
| Installation dimensions ceiling thickness MIN [mm] | 3 |
| Installation dimensions ceiling thickness MAX [mm] | 18 |
| Diameter | Installation dimensions diameter | Installation dimensions height |
|---|---|---|
| 221 mm | 190 mm | 180 mm |
PSU 1.4A 45W DA 1CH IP20
PSU 1A 50W DA8 2CH IP20
