LT2 XT420

Track spotlight XT

LT2 XT420 40 30 930 DA

Product features

Classic track spotlight for targeted accentuation in shop and shop fitting
Housing made of die-cast aluminum, powder-coated. Visible housing parts powder-coated. Can be rotated and swiveled for precise illumination. Different reflectors available for different areas of application. Bayonet lock for easy reflector change. Integrated power supply.
Adapter for 3-phase rail system
Other housing colors / surfaces on request

Technical specifications

Control Luminous flux Light color Beam angle Power consumption Protection class
DALI 3980 lm
3000 K
30 °
39.4 W IP20

Characteristics

Lifespan 50,000 h
Ambient temperature +5 ... + 35 ° C
Storage & transport temperature -25 ... + 70 ° C
Nominal voltage AC 220 ... 240 V
Nominal frequency 50/60 Hz
Weight 1.6 kg
Light output 101 lm / W
Housing material aluminum
Protection class I.
Protection class IP20
Connection type Busbar
Color fidelity SDCM 3
Colour reproduction typ. 92

Dimensions

Length (L) Diameter
125 mm 106 mm
